System Interface Unit (SIU)
MPC5553/MPC5554 Microcontroller Reference Manual, Rev. 5
Freescale Semiconductor 6-81
6.3.1.12.92 Pad Configuration Register 191 (SIU_PCR191)
The SIU_PCR191 register controls the pin function, direction, and static electrical attributes of the
EMIOS[12]_SOUTC_GPIO[191] pin. Only the output of EMIOS[12] is connected to the pin.
Figure 6-104. EMIOS[12]_SOUTC_GPIO[191] Pad Configuration Register (SIU_PCR191)
Refer to Table 6-16 for bit field definitions.
6.3.1.12.93 Pad Configuration Register 192 (SIU_PCR192)
The SIU_PCR192 register controls the pin function, direction, and static electrical attributes of the
EMIOS[13]_SOUTD_GPIO[192] pin. Only the output of EMIOS[13] is connected to the pin.
Figure 6-105. EMIOS[13]_SOUTD_GPIO[192] Pad Configuration Register (SIU_PCR192)
Refer to Table 6-16 for bit field definitions.
Address: Base + 0x01BE Access: Read / write[4:7, 10:15]
0123456789101112131415
R 0000
PA OBE
1
1
The OBE bit must be set to 1 for GPIO[191] when configured as an output.
IBE
2
2
When configured as EMIOS or GPO, set the IBE bit to 1 to reflect the pin state in the corresponding GPDI register. Clear the
IBE to 0 to reduce power consumption. The IBE bit must be set to 1 for GPIO[191] when configured as an input.
00
ODE HYS SRC WPE WPS
W
RESET: 000000000000001U
3
3
The weak pullup/down selection at reset for the EMIOS[12] pin is determined by the WKPCFG pin.
Address: Base + 0x01C0 Access: Read / Write[4:7, 10:15]
0123456789101112131415
R 0000
PA OBE
1
1
The OBE bit must be set to 1 for GPIO[192] when configured as an output.
IBE
2
2
When configured as EMIOS or GPO, set the IBE bit to 1 to reflect the pin state in the corresponding GPDI register. Clear the
IBE to 0 to reduce power consumption. The IBE bit must be set to 1 for GPIO[192] when configured as an input.
00
ODE HYS SRC WPE WPS
W
RESET: 000000000000001U
3
3
The weak pullup/down selection at reset for the EMIOS[13] pin is determined by the WKPCFG pin.
