8.2.1.9 Flash ECC Data High Register (ECSM_FEDRH)
The ECSM_FEDRH and ECSM_FEDRL are 32-bit registers for capturing the data associated with the
last, properly-enabled ECC event in the flash memory. Depending on the state of the ECSM_ECR, an ECC
event in the flash causes the address, attributes and data associated with the access to be loaded into the
ECSM_FEAR, ECSM_FEMR, ECSM_FEAT and ECSM_FEDRs, and the appropriate flag (FNCE) in the
ECSM_ESR to be asserted.
The data captured on a multi-bit non-correctable ECC error is undefined.
01234567
R WRITE SIZE PROT0 PROT1 PROT2 PROT3
W
Reset UUUUUUUU
Reg Addr Base + 0x0057
1
“U” signifies a bit that is uninitialized.
Figure 8-6. Flash ECC Attributes Register (ECSM_FEAT)
Table 8-8. ECSM_FEAT Field Descriptions
Bits Name Description
0WRITEWrite. The reset value of this field is undefined.
0 System bus read access
1 System bus write access
1–3 SIZE
[0:2]
Size. The reset value of this field is undefined.
000 8-bit System bus access
001 16-bit System bus access
010 32-bit System bus access
011 64-bit System bus access
1xx Reserved
4 PROT0 Protection: cache. The reset value of this field is undefined.
0 Non-cacheable
1 Cacheable
5 PROT1 Protection: buffer. The reset value of this field is undefined.
0 Non-bufferable
1Bufferable
6 PROT2 Protection: mode. The reset value of this field is undefined.
0 User mode
1 Supervisor mode
7 PROT3 Protection: type. The reset value of this field is undefined.
0 I-Fetch
1 Data
