MacDon M1170 - Accessing Header Information

214733 101 Revision A
1018967
A
B
C
D
Figure 3.121: Windrower Information Menu
The windrower information menu displays the following
information:
• Engine hours (A)
• Windrower total hours (B)
• Total acres (C)
• Windrower total header hours (D)
Accessing Header Information
1014684
A
B
C
Figure 3.122: Opening the Main Menu
1. Press soft key 5 (A) to open the main menu.
2. To scroll to the INFORMATION icon (C), use the Harvest
Performance Tracker (HPT) scroll knob (B) or the ground
speed lever (GSL) scroll wheel (not shown).
3. Press the HPT scroll knob (B) or the GSL SELECT button (not
shown) to select the highlighted INFORMATION icon.
1014726
A
Figure 3.123: Header Information Submenu Icon
4. Scroll to the HEADER INFORMATION submenu icon (A), and
press SELECT to display the header information menu.
OPERATOR’S STATION
