MacDon M1170 - Accessing Software Information

214733 102 Revision A
1018968
A
B
C
D
E
Figure 3.124: Header Information Menu
The header information menu displays the following
information:
• Header (A)
• Header hours (B)
• Total acres (B)
• Sub-acres (D) (resettable)
NOTE:
If you select reset (E), the message RESET YES/NO appears on the
display. Select YES to reset the sub-acres to zero and return to
the same highlighted sub-acres. Select NO or press the BACK or
HOME button to dismiss the message without resetting the sub-
acres. The sub-acres are also resetable from run screen 3. Refer
to Run Screen 3 – Performance Data, page 132.
Accessing Software Information
1014684
A
B
C
Figure 3.125: Opening the Main Menu
1. Press soft key 5 (A) to open the main menu.
2. To scroll to the INFORMATION icon (C), use the Harvest
Performance Tracker (HPT) scroll knob (B) or the ground
speed lever (GSL) scroll wheel (not shown).
3. Press the HPT scroll knob (B) or the GSL SELECT button (not
shown) to select the highlighted INFORMATION icon.
1014737
A
Figure 3.126: Software Information Submenu Icon
4. Scroll to the SOFTWARE INFORMATION submenu icon (A),
and press SELECT to display the module information menu.
OPERATOR’S STATION
