4.9.2 Setting Float Options with Fixed Deck
When using an auger or rotary header, the DECK SHIFT buttons can be used to store three different float settings. This is
useful when cutting in varying ground conditions, or when having one side lighter is desirable (such as cutting along wheel
tracks or irrigation borders).
CAUTION
Check to be sure all bystanders have cleared the area.
Figure 4.286: GSL
1. Start the engine and use the HEADER TILT switches (A) and
(B) on the ground speed lever (GSL) to set header tilt to the
MID-RANGE position.
Figure 4.287: Header Engage Switch
2. Engage header by pushing and holding the HEADER
ENGAGE switch (A) down, and pulling up on collar (B).
OPERATION
