3.3 Operator’s Seat Adjustments
The operator’s seat has several adjustments. Refer to the following sections for a description and the location of each
adjustment. Some seat features are only available with the deluxe cab option.
3.3.1 Armrest
1019743
A
B
Figure 3.4: Operator’s Seat Armrest
A - Standard Seat B - Deluxe Seat
Raise armrest for easier access to seat.
Lower armrest after seat belt is buckled.
3.3.2 Armrest Angle
Use controls to adjust angle of armrest.
1012787
A
Figure 3.5: Operator’s Seat Armrest Angle Controls
• Rotate knob (A) clockwise to increase armrest angle.
• Rotate knob (A) counterclockwise to decrease armrest angle.
