MacDon M1170 - Cushion Tilt (Deluxe Cab Only); Cushion Extension (Deluxe Cab Only)

214733 46 Revision A
3.3.9 Cushion Tilt (Deluxe Cab Only)
Use controls to adjust the deluxe seat’s cushion tilt.
1012784
A
Figure 3.12: Deluxe Seat Cushion Tilt Controls
1. Pull lever (A) up to release.
2. Tilt seat cushion up or down.
3. Release lever (A).
3.3.10 Cushion Extension (Deluxe Cab Only)
Use controls to adjust seat cushion extension fore-aft.
1012785
A
Figure 3.13: Deluxe Seat Cushion Extension Controls
1. Pull lever (A) up to release.
2. Move cushion forward or rearward.
3. Release lever (A).
OPERATOR’S STATION
