214733 398 Revision A
Table 6.1 Available Float Spring Kits for Different Header Types and Configurations (continued)
Header Type
Description
Header Configuration
Additional
Float Spring Kits
D145XL
12.2 m (40 ft.)
double reel,
double knife, untimed
Base MD #B6047
D145XL
12.2 m (40 ft.)
double reel,
double knife, untimed
Transport MD #B6047
6.3.2 Double Booster Spring Kit (External)
Available for headers over 2812 kg (6200 lb.) to increase the float capacity.
The Double Booster Spring kit (MD #B6106) is used together with the Booster Spring kit (MD # B6047) to add a second
booster spring. Refer to 6.3.1 Booster Spring Kit (External), page 397. Kit instruction MD #147826 is included in the bundle.
Table 6.2 Available Float Spring Kits for Different Header Types and Configurations
Header Type
Description
Header Configuration
Additional
Float Spring Kits
D145XL
13.7 m (45 ft.) double reel,
double knife, untimed
Transport
Upper Cross Auger
Vertical Knives
MD #B6106
6.3.3 Double Windrow Attachment (DWA)
This kit allows auger headers to lay a double windrow when installed on a windrower. The kit includes a draper deck,
linkage assembly, hydraulics, and installation instructions.
MD #C2006 consists of:
• MD #B5973 Deck
• MD #B5974 Mounting frame and hydraulic/electrical connections
• Double Windrow Attachment (DWA) manual
6.3.4 Double Windrow Attachment (DWA) Shutoff Kit
For M1240 owners with a DWA who have both R85 disc and D1 Series draper headers, or for M1170 owners with a DWA
who have both A40DX auger and D1 Series draper headers, this kit allows Operators to stop the DWA draper when running
a D1 Series draper header.
MD #299704
Instruction MD #214491 included with the kit.
OPTIONS AND ATTACHMENTS
