214733 342 Revision A
5.14 Annual Service
Complete the following maintenance tasks annually. It is recommended that annual maintenance be done prior to start of
operating season.
• Check battery charge and fluid level. Refer to 5.14.1 Batteries, page 342.
• Check steering linkages. Refer to 5.14.2 Checking Steering Link Pivots, page 352.
• Check A/C blower. Refer to 5.14.3 Air Conditioning Evaporator, page 354.
• Check antifreeze concentration. Refer to 5.14.4 Checking Engine Coolant Strength, page 357.
5.14.1 Batteries
Table 5.5 Battery Specification
Rating
Group
CCA (min)
Volt
Maximum Dimension
Heavy duty, off-road,
vibration resistant
31A 760 12
334 x 188 x 232 mm
(13 x 7.4 x 9.13 in.)
Maintaining a Battery
CAUTION
Do NOT attempt to service battery unless you have the proper equipment and experience to perform the job. Have it
done by a qualified Dealer.
• Check battery charge once a year, more often if operating in cold weather. Hydrometer readings should be 1.260 to
1.300. Readings below 1.250 indicate charging is required. Refer to Charging a Battery, page 344.
• Keep batteries clean by wiping with a damp cloth.
• Keep all connections clean and tight. Remove any corrosion and wash terminals with a solution of baking soda and
water. A light coating of grease on terminals (after cables are attached) will reduce corrosion.
• To prolong battery life, store batteries fully charged and at -7° to +26°C (+20° to +80°F). Check voltage after storage and
recharge as needed according to battery and charger manufacturer recommendations.
• Do NOT stack storage batteries on top of each other.
• Test batteries every 4–6 months and recharge if necessary.
• Disconnect battery ground if storing the windrower for more than 3 months.
MAINTENANCE AND SERVICING
