6.3 Header Operation
6.3.1 Booster Spring Kit (External)
This kit is available for headers over 2812 kg (6200 lb.) to increase the float capacity.
MD #B6047 – Booster Spring kit (external) includes two springs (one for each side) and mounting brackets. Kit instruction
MD #147825 is included in the bundle.
There is also a Double Booster Spring kit (MD #B6106) that is used together with the Booster Spring kit (external) to add on
a second booster spring. Refer to 6.3.2 Double Booster Spring Kit (External), page 398.
Table 6.1 Available Float Spring Kits for Different Header Types and Configurations
Header Type
Description
Header Configuration
Additional
Float Spring Kits
D130XL
9.1 m (30 ft.)
single reel,
double knife, timed
Transport
—
D130XL
9.1 m (30 ft.)
single reel,
double knife, timed
Transport
Upper Cross Auger
Vertical Knives
MD #B6047
D135XL
10.8 m (35 ft.)
single reel,
double knife, untimed
Base
—
D135XL
10.8 m (35 ft.)
single reel,
double knife, untimed
Transport
MD #B6047
D135XL
10.8 m (35 ft.)
single reel,
double knife, untimed
Transport
Upper Cross Auger
Vertical Knives
MD #B6047
D135XL
10.8 m (35 ft.)
double reel,
double knife, untimed
Base
—
D135XL
10.8 m (35 ft.)
double reel,
double knife, untimed
Transport MD #B6047
D135XL
10.8 m (35 ft.)
double reel,
double knife, untimed
Transport
Upper Cross Auger
Vertical Knives
MD #B6047
D140XL
12.2 m (40 ft.)
double reel,
double knife, untimed
Base
—
D140XL
12.2 m (40 ft.)
double reel,
double knife, untimed
Transport
MD #B6047
D140XL
12.2 m (40 ft.)
double reel,
double knife, untimed
Transport
Upper Cross Auger
Vertical Knives
MD #B6047
