4.2.2 Harvest Performance Tracker Symbols
Figure 4.2: Harvest Performance Tracker Symbols
1016181
A
B
C
D
E
F
G
H
J
K
L
M
N
P
Q
R
S
T
U
V
W
X
Y
Z
AA
AB
AC
A - Knife B - Knife Pressure C - Reel
D - Reel Speed E - Reel Height F - Reel Fore-Aft
G - Draper H - Draper Pressure J - Draper Speed
K - Header Height L - Header Tilt M - Header Float
N - DWA Raise P - DWA Lower Q - Disc
R - Disc Pressure S - Disc Speed T - DEF
U - SCR Conditioning Manual V - SCR Conditioning Inhibit W - High Exhaust System Temperature
X - Engine rpm Y - Fuel Z - Water in Fuel
AA - Parking Brake AB - Climate Control AC - Swath Compressor
