MacDon M1170 - Replacing LED Lights (Deluxe Cab Only)

214733 372 Revision A
Replacing LED Lights (Deluxe Cab Only)
WARNING
To avoid bodily injury or death from unexpected startup of the machine, always stop the engine and remove the key
from the ignition before leaving the operator’s seat for any reason.
The M1170 Windrower deluxe cab is equipped with the following LED lights (MD #207062):
• Four LED field lights (A)
• Two LED stubble lights (B)
• Two LED rear work lights (C)
The bulb of an LED light cannot be replaced. If a light fails, please contact your MacDon Dealer for replacement parts.
Figure 5.183: LED Light Locations – Deluxe Cab Only
1018907
B
C
A
MAINTENANCE AND SERVICING
