MacDon M1170 - Header Drive Troubleshooting; Conversion Chart

214733 409 Revision A
7.4 Header Drive Troubleshooting
Problem Solution
Section
Symptom: Header drive is not engaging.
OPERATOR PRESENCE switch not
closed or faulty
Occupy operator’s seat or replace
switch. Contact your Dealer.
Contact Dealer
OPERATOR PRESENCE switch not
closed or faulty
Occupy operator’s seat or replace
switch. Contact your Dealer.
Contact Dealer
Appropriate solenoid not being
energized by activating switch
Contact Dealer. Contact Dealer
Couplers not connected Contact Dealer. Contact Dealer
Faulty pump or flow controls
Contact Dealer. Contact Dealer
Control solenoids disconnected Contact Dealer. Contact Dealer
Header ID not detected
Attach header or check wiring. Contact
your Dealer.
Contact Dealer
Symptom: Header drive lacks power.
Relief valve setting too low Contact Dealer. Contact Dealer
Header drive overload
Reduce ground speed.
—
Symptom: Warning alarm sounds.
Header drive overload Reduce ground speed.
—
Relief valve setting too low Contact Dealer. Contact Dealer
TROUBLESHOOTING
