3.3.5 Fore-Aft Isolator Control
Use controls to lock the seat’s fore-aft isolator.
1012790
A
Figure 3.8: Operator’s Seat Fore-Aft Isolator Controls
• Push lever (A) down to lock
• Pull lever (A) up to unlock
3.3.6 Tilt
Use controls to adjust the seat’s tilt.
1012788
A
Figure 3.9: Operator’s Seat Tilt Controls
1. Pull lever (A) up to release.
2. Position seat back as desired.
3. Release lever (A).
