3.11 Operator Amenities
The operator’s station includes the following amenities:
1019627
A
E
B
C
D
Figure 3.39: Console
Operator’s console
• Auxiliary power outlets (A)
• USB jack (B)
• Utility tray under armrest (C)
• Utility tray (D)
• Cup holder (E)
1014912
A
Figure 3.40: Window Shades
Window shades
Retractable window shades (A) are located at the front and rear
windows.
