MacDon M1170 - Activating Bluetooth Feature; Pairing a Bluetooth Device

214733 65 Revision A
Activating Bluetooth
®
Feature
The Bluetooth
®
feature must be activated to allow mobile device pairing.
To activate the Bluetooth
®
feature, follow this procedure:
1015835
A
B
C
Figure 3.47: Bluetooth
®®
Radio
1. Press POWER button (A) to turn the radio on.
2. Press and hold VOL/SEL knob (B) for two seconds. MENU is
displayed on screen (C).
3. Rotate VOL/SEL (B) to highlight BT SET menu and press
VOL/SEL to select. BLUETOOTH ON/OFF is displayed (C).
4. Press VOL/SEL to select BLUETOOTH.
5. Rotate VOL/SEL knob to display ON and press VOL/SEL to
select.
6. Rotate VOL/SEL knob and select DISCOVER.
7. Rotate VOL/SEL knob to display ON and press VOL/SEL to
select.
Pairing a Bluetooth
®
Device
The installed radio allows the operator to pair a Bluetooth
®
phone or audio device. Before proceeding, check that
Bluetooth
®
is enabled and radio has been set to DISCOVER mode. Refer to Activating Bluetooth
®
Feature, page 65.
To pair a mobile device, follow this procedure:
1015838
A
B
C
Figure 3.48: Radio Display
1. Press POWER button (A) to turn radio ON.
This will set the radio to Bluetooth
®
discover mode if the
Bluetooth
®
feature has been activated. Refer to Activating
Bluetooth
®
Feature, page 65.
2. Turn the mobile device’s Bluetooth
®
to ON. Refer to the
device’s operator’s manual. The radio appears as a
discoverable device.
3. Select CD-5000 BT on the mobile device to connect.
NOTE:
A passkey is required to connect to the Bluetooth
®
radio.
The default passkey is four zeros (0000).
4. Enter the default passkey 0000. The radio will display
CONNECTED (B) and the Bluetooth
®
icon (C) appears in the
upper right corner of the screen.
