Figure 3.45: Manual Storage Location
3. When finished with the radio manual, place the manual in
the manual storage case (A) located behind the
training seat.
1015973
1023352
A
B
Figure 3.46: Relay Module Cover
4. Close the relay module cover (B) and turn latch (A) to
lock it.
