3.4 Training Seat
A folding wall-mounted training seat (with seat belt) is provided.
WARNING
• The training seat is provided for use by an experienced machine Operator while training a new Operator.
• The training seat is NOT intended as a passenger seat or for use by children. Use the seat belt whenever operating
the machine or riding as a Trainer.
• Keep all other riders off the machine.
1012793
A
Figure 3.16: Training Seat
To store training seat, lift seat and secure with latch (A).
To lower training seat, pull latch (A) and lower seat.
