MacDon M1170 - Component Location

214733 37 Revision A
2.4 Component Location
Figure 2.3: Front Cab-Forward View
1012671
A
B
C
D
E
F
G
H
F
J
K
L
M
N
E
A - Header Lift Leg B - Header Float Springs C - Operator’s Station
D - Windshield Wiper E - Turn Signal/Hazard Lights F - Tail lights Engine-Forward
G - Field/Road Lights
4
H - Handholds J - Mirror
K - Door L - Maintenance Platform M - Center-Link
N - Horn
PRODUCT OVERVIEW
4. Standard cabs have halogen lights; deluxe cabs have LED lights.
