MacDon M1170 - Transport; Ballast

214733 400 Revision A
6.4 Transport
6.4.1 Ballast
Ballast kits are for draper headers only. For operation on steep hills, additional ballast sets (beyond the recommendation in
the table) may be installed.
Initial rear ballast package (MD #B6053): 1 unit (163 kg [360 lb.])
Additional rear ballast package (MD #B6054): 2 units (163 kg [360 lb.] each)
Installation instructions included.
Table 6.3 Ballast
Header Type
Description
Installed Options
Base Kit
Additional
Kits
Additional
Float Springs
D125X
25 foot, single reel,
double knife, timed
–
00 0
D130XL
30 foot, single reel,
double knife, timed
Transport 1 0 0
D130XL
30 foot, single reel,
double knife, timed
Transport + upper cross
auger + vertical knives
1
0 B6047
D135XL
35 foot, single reel,
double knife, untimed
Base 1 1 0
D135XL
35 foot, single reel,
double knife, untimed
Transport
1 1 B6047
D135XL
35 foot, single reel,
double knife, untimed
Transport + upper cross
auger + vertical knives
1
2 B6047
D135XL
35 foot, double reel,
double knife, untimed
Base
11 0
D135XL
35 foot, double reel,
double knife, untimed
Transport 1 1
B6047
D135XL
35 foot, double reel,
double knife, untimed
Transport + upper cross
auger + vertical knives
1 2 B6047
D140XL
40 foot, double reel,
double knife, untimed
Base 1 1
0
D140XL
40 foot, double reel,
double knife, untimed
Transport 1 1 B6047
D140XL
40 foot, double reel,
double knife, untimed
Transport + upper cross
auger + vertical knives
1
2 B6047
D145XL
45 foot, double reel,
double knife, untimed
Base 1 1 B6047
D145XL
45 foot, double reel,
double knife, untimed
Transport
1 2 B6047
D145XL
45 foot, double reel,
double knife, untimed
Transport + upper cross
auger + vertical knives
1
2 B6106
