MacDon M1170 - Lateral Isolation Lockout (Deluxe Cab Only); Heating;Cooling (Deluxe Cab Only)

214733 47 Revision A
3.3.11 Lateral Isolation Lockout (Deluxe Cab Only)
1012821
A
Figure 3.14: Deluxe Seat Lateral Isolation Controls
Use the controls (A) to lock or unlock the deluxe seat ’ s lateral
isolation lockout.
3.3.12 Heating/Cooling (Deluxe Cab Only)
WARNING
• Do NOT use the seat heating or cooling system if you have a diminished ability to sense temperature, a reduced
ability to feel pain, or have sensitive skin. There is a possibility that some people may suffer heat-induced burns or
excessive cooling when using the system.
• Do NOT place anything on the seat that insulates against heat or cooling, such as a blanket or cushion. These items
may cause the seat heating or cooling system to overheat and cause a heat-induced burn to the seat occupant, or
damage to the seat itself.
Use the controls to adjust the heating/cooling of deluxe operator’s seat.
1012824
A
B
Figure 3.15: Deluxe Seat Heating and Cooling Controls
Seat heating/cooling switch (A)
• Press switch forward for COOL
• Press switch back for HEAT
Heating/cooling high/low/off switch (B)
• Press switch up for HIGH
• Press switch down for LOW
• Center switch for OFF
OPERATOR’S STATION
