214733 366 Revision A
Figure 5.169: Left Cab-Forward Headlight – Right
Opposite
2. Adjust lights by hand as required. Loosen/tighten nuts (A) if
necessary.
Adjusting Front Field Lights
Adjust field lights when in the field (or equivalent) to best suit Operator preference.
WARNING
To avoid bodily injury or death from unexpected startup of the machine, always stop the engine and remove the key
from the ignition before leaving the operator’s seat for any reason.
Figure 5.170: Windrower in Cab-Forward
1. Hold onto handholds (A) on the cab front corners, and
stand on header anti-slip strips.
MAINTENANCE AND SERVICING
