214733 78 Revision A
3.17 Harvest Performance Tracker (HPT) Display
The HPT display settings are preset at the factory. This section explains how to adjust the settings.
3.17.1 Harvest Performance Tracker (HPT) Screen Layout
The appearance and functions of the HPT depend on the type of header attached.
Figure 3.69: Run Screen 1 (Draper Header Shown)
A - Left Gauge Cluster B - Header Information C - Current Header Position D - Telltales
OPERATOR’S STATION
