214733 129 Revision A
CAUTION
Operate both steering wheel and ground speed lever slowly while becoming familiar with the machine. Steering can be
sensitive; avoid the tendency of new Operators to overcorrect.
Figure 4.37: Operator Console
8. If more tractive (lugging) power is required (e.g., when
driving up a ramp, up a hill, or out of a ditch):
a. Move the GSL (B) closer to NEUTRAL.
b. Reduce max speed setting to 16 km/h (10 mph) by
holding the shift button on the GSL while scrolling
downwards, or by reducing the max speed setting
using the QuickMenu. Refer to Adjusting Ground Speed
Limit, page 125.
9. Once the lugging condition no longer exists:
a. Set GSL (B) to NOT MORE THAN HALF maximum
forward speed.
b. Adjust the maximum speed setting back to 43 km/h
(27 mph). Refer to Adjusting Ground Speed Limit, page
125.
OPERATION
