214733 220 Revision A
Figure 4.239: Adjusting Knife Alarm Pressure
4. Scroll to the knife alarm pressure setting (A), and press
knob to select it.
5. Turn knob to change the ALARM set-point in window (A).
Scrolling past the highest setting turns the alarm off. When
the alarm point is off, the digital value is replaced with
three dashed lines.
6. Adjust knife alarm pressure set-point to desired value, and
press knob to select it. Factory setting is 23,442 kpa
(3400 psi).
OPERATION
