214733 436 Revision A
Fault Codes
Telltale
Short
Description
Full Fault
Description
Recommended
Fix/Check Message
SA SPN
FMI
104 521071 3
Electrical
System
Left Wheel Motor
High Alarm
Sensor voltage above 4.5 V. Check for wiring
damage and replace sensor as necessary.
104 521072 2
Electrical
System
Right Wheel Motor Low Alarm
Sensor voltage below 0.5 V. Check sensor power
supply and replace sensor as necessary.
104 521072 3
Electrical
System
Right Wheel Motor High Alarm
Sensor voltage above 4.5 V. Check for wiring
damage and replace sensor as necessary.
104 521460 1
Windrower Wheel Speed
Left Wheel Speed Sensor
Check left wheel speed sensor and wiring.
Reading speed off Right wheel only. Auto-reel
and auto-draper speed performance will be
impacted while turning.
104 521460 2
Windrower Wheel Speed Right Wheel Speed Sensor
Check right wheel speed sensor and wiring.
Reading speed off left wheel only. Auto-reel and
auto-draper speed performance will be impacted
while turning.
104 521460 3
Windrower Wheel Speed
Left & Right Wheel Speed
Sensor
Check right and left wheel speed sensors and
wiring. Acre tracking, auto-reel and auto-draper
speed features will be disabled.
104 521073 2
Electrical
System
Knife/Disc Speed
Low Alarm
Sensor voltage below 0.5 V. Check sensor power
supply. Check sensor adjustment and replace if
necessary.
104 521073 3
Electrical
System
Knife/Disc Speed
High Alarm
Sensor voltage above 4.5 V. Check for wiring
damage. Check sensor adjustment and replace if
necessary.
104 521073 31
Electrical
System
Knife/Disc Speed
Condition Exists
No knife/disc speed feedback. Estimated speed
will be used, This will exclude knife/disc speed
changes when selecting buttons A, B and C on
ground speed lever.
104 521390 0
Windrower Knife Speed Above Norm Most Severe
Knife speed above max allowable for
header type. Contact Dealer.
104 521074 2
Electrical
System
Reel Speed Low Alarm
Sensor voltage below 0.5 V. Check sensor power
supply. Check sensor adjustment and replace if
necessary.
