MacDon M1170 - Page 458

214733 442 Revision A
Fault Codes
Telltale
Short
Description
Full Fault
Description
Recommended
Fix/Check Message
SA SPN
FMI
104 521379
4
Electrical System
Right Lateral Tilt O/P
Overload
High current on circuit. Check wiring for damage. Contact Dealer.
104 521380 3
Electrical System
Right Float Adjust O/P
Open Load
Check wiring for damage or breaks. Contact Dealer.
104 521380 4
Electrical System
Right Float Adjust O/P
Overload
High current on circuit. Check wiring for damage. Contact Dealer.
104 521381 3
Electrical System
Left Float Adjust O/P
Open Load
Check wiring for damage or breaks. Contact Dealer.
104 521381
4
Electrical System
Left Float Adjust O/P
Overload
High current on circuit. Check wiring for damage. Contact Dealer.
104 521087 2
Electrical System
Master Controller Disabled Contact Dealer.
104 521087 3
Electrical System
Master Controller High Temperature
Module has exceeded max operating temperature. Allow module to cool down before continuing operation.
104 521087
4
Electrical System
Master Controller Low Batt Voltage
Battery voltage is low, check charging system. Contact Dealer.
104 521087
5
Electrical System
Master Controller High Batt Voltage Battery voltage is high. Contact Dealer.
104 521087 7
Electrical System
Master Controller Vref Error
Reference voltage error. Check wiring for damage. The following sensors may be affected: Left Hand Wheel Speed Right Hand Wheel Speed Fuel Level Ground Speed Lever Position
104 521087 10
Electrical System
Master Controller MultiAddress Check address wiring.
104 521087 8
Electrical System
Master Controller
Address Error
CAN Address Error. Contact Dealer.
104 521092 1
Electrical System
Ext. Module, Firewall Disabled Contact Dealer.
104 521092 2
Electrical System
Ext. Module, Firewall High Temperature
Module has exceeded max operating temperature. Allow module to cool down before continuing operation.
REFERENCE
