MacDon M1170 - Page 471

214733 455 Revision A
Fault Codes
Telltale
Short
Description
Full Fault
Description
Recommended
Fix/Check Message
SA SPN
FMI
178 521194
6
Electrical System
High Beam, Engine Fwd
BK2 Relay Normally open contact is shorted
Replace relay.
178 521194
7
Electrical System
High Beam, Engine Fwd
BK2 Relay Normally closed contact is shorted
Replace relay.
178 521226 1
Electrical System
Right Turn Signal
BK3 Relay coil open or not present
Check chassis module for missing replay. Replace relay.
178 521226 2
Electrical System
Right Turn Signal
BK3 Relay Coil shorted or failed relay driver
Replace relay.
178 521226 3
Electrical System
Right Turn Signal
BK3 Relay Normally Open contact is open
Replace relay.
178 521226
4
Electrical System
Right Turn Signal
BK3 Relay Normally Closed contact is open
Replace relay.
178 521226
5
Electrical System
Right Turn Signal
BK3 Relay coil is not receiving power
Contact Dealer.
178 521226 6
Electrical System
Right Turn Signal
BK3 Relay Normally open contact is shorted
Replace relay.
178 521226
7
Electrical System
Right Turn Signal
BK3 Relay Normally closed contact is shorted
Replace relay.
178 521210 1
Electrical System
Low Beam Lights, EF
BK5 Relay coil open or not present
Check chassis module for missing replay. Replace relay.
178 521210 2
Electrical System
Low Beam Lights, EF
BK5 Relay Coil shorted or failed relay driver
Replace relay.
178 521210 3
Electrical System
Low Beam Lights, EF
BK5 Relay Normally Open contact is open
Replace relay.
178 521210 4
Electrical System
Low Beam Lights, EF
BK5 Relay Normally Closed contact is open
Replace relay.
178 521210
5
Electrical System
Low Beam Lights, EF
BK5 Relay coil is not receiving power
Contact Dealer.
178 521210 6
Electrical System
Low Beam Lights, EF
BK5 Relay Normally open contact is shorted
Replace relay.
178 521210 7
Electrical System
Low Beam Lights, EF
BK5 Relay Normally closed contact is shorted
Replace relay.
REFERENCE
