J1939
SPN
J1939
FMI
Telltale
Lamp
Cummins
Fault Code
J1939_SPN Description
Detail
1081 9
Check
Engine
Amber
3555 Engine Wait to Start Lamp
Engine Wait to Start Lamp -
Abnormal update rate
1172 3
Check
Engine
Amber
691
Engine Turbocharger 1
Compressor Intake
Temperature
Turbocharger 1 Compressor
Intake Temperature Circuit -
Voltage above normal, or shorted
to high source
1172 4
Check
Engine
Amber
692
Engine Turbocharger 1
Compressor Intake
Temperature
Turbocharger 1 Compressor
Intake Temperature Circuit -
Voltage below normal, or shorted
to low source
1176 2
Check
Engine
Amber
743
Engine Turbocharger 1
Compressor Intake
Pressure
Turbocharger 1 Compressor
Intake Pressure - Data is erratic,
intermittent, or incorrect
1176
3
Check
Engine
Amber
741
Engine Turbocharger 1
Compressor Intake
Pressure
Turbocharger 1 Compressor
Intake Pressure Circuit - Voltage
above normal, or shorted to
high source
1176
4
Check
Engine
Amber
742
Engine Turbocharger 1
Compressor Intake
Pressure
Turbocharger 1 Compressor
Intake Pressure Circuit - Voltage
below normal, or shorted to
low source
1194 13
Stop
Engine
Red
3298
Anti-theft Encryption Seed
Present Indicator
Anti-theft Encryption Seed - Out
of Calibration
1209 2
Check
Engine
Amber
2554
Engine Exhaust Gas
Pressure 1
Exhaust Gas Pressure 1 - Data is
erratic, intermittent, or incorrect
1209 3
Check
Engine
Amber
2373
Engine Exhaust Gas
Pressure 1
Exhaust Gas Pressure Sensor 1
Circuit - Voltage above normal, or
shorted to high source
1209
4
Check
Engine
Amber
2374
Engine Exhaust Gas
Pressure 1
Exhaust Gas Pressure Sensor 1
Circuit - Voltage below normal, or
shorted to low source
1231 2
Check
Engine
None
3329
J1939 Network #2
J1939 Network #2 - Data is
erratic, intermittent, or incorrect
1235 2
Check
Engine
None 3331
J1939 Network #3
J1939 Network #3 - Data is
erratic, intermittent, or incorrect
1323 31
Check
Engine
Amber
1654
Engine Misfire Cylinder #1
Engine Misfire Cylinder 1 -
Condition exists
1324 31
Check
Engine
Amber
1655
Engine Misfire Cylinder #2
Engine Misfire Cylinder 2 -
Condition exists
1325 31
Check
Engine
Amber
1656
Engine Misfire Cylinder #3
Engine Misfire Cylinder 3 -
Condition exists
1326 31
Check
Engine
Amber
1657
Engine Misfire Cylinder #4
Engine Misfire Cylinder 4 -
Condition exists
1347 3
Check
Engine
Amber
272
Engine Fuel Pump
Pressurizing Assembly #2
Engine Fuel Pump Pressurizing
Assembly 1 Circuit - Voltage
REFERENCE
