214733 489 Revision A
J1939
SPN
J1939
FMI
Telltale
Lamp
Cummins
Fault Code
J1939_SPN Description
Detail
3695 2
Check
Engine
None 6568
Aftertreatment
Regeneration Inhibit Switch
Aftertreatment Regeneration
Inhibit Switch - Data is erratic,
intermittent, or incorrect
3750
14
Check
Engine
Amber
5938
Diesel Particulate Filter 1
Conditions Not Met for
Active Regeneration
Diesel Particulate Filter 1
Conditions Not Met for Active
Regeneration – Condition exists
4096 31
Check
Engine
Amber
3547
NOx limits exceeded due to
Empty Diesel Exhaust
Fluid Tank
Aftertreatment Diesel Exhaust
Fluid Tank Empty -
Condition exists
4185 31
Check
Engine
Amber
1427
Overspeed Shutdown
Relay Driver
Overspeed Shutdown Relay Driver
Diagnostic has detected an error -
Condition exists
4186 31
Check
Engine
Amber
1428
Low Oil Pressure Shutdown
Relay Driver
Low Oil Pressure (LOP) Shutdown
Relay Driver Diagnostic has
detected an error -
Condition exists
4187 31
Check
Engine
Amber
1429
High Engine Temperature
Shutdown Relay Driver
High Engine Temperature (HET)
Shutdown Relay Driver Diagnostic
has detected an error - Condition
exists
4188 31
Check
Engine
Amber
1431
Pre-Low Oil Pressure
Indicator Relay Driver
Pre-Low Oil Pressure Warning
Relay Driver Diagnostic has
detected an error -
Condition exists
4223 31
Check
Engine
Amber
1432
Pre-High Engine
Temperature Warning
Relay Driver
Pre-High Engine Temperature
Warning Relay Driver Diagnostic
has detected an error - Condition
exists
4334 2
Check
Engine
Amber
3596
Aftertreatment 1 Diesel
Exhaust Fluid Doser
Absolute Pressure
Aftertreatment 1 Diesel Exhaust
Fluid Pressure Sensor - Data is
erratic, intermittent, or incorrect
4334 3
Check
Engine
Amber
3571
Aftertreatment 1 Diesel
Exhaust Fluid Doser
Absolute Pressure
Aftertreatment 1 Diesel Exhaust
Fluid Pressure Sensor - Voltage
above normal, or shorted to high
source
4334 4
Check
Engine
Amber
3572
Aftertreatment 1 Diesel
Exhaust Fluid Doser
Absolute Pressure
Aftertreatment 1 Diesel Exhaust
Fluid Pressure Sensor - Voltage
below normal, or shorted to
low source
4334 16
Check
Engine
Amber
3575
Aftertreatment 1 Diesel
Exhaust Fluid Doser
Absolute Pressure
Aftertreatment 1 Diesel Exhaust
Fluid Pressure Sensor - Data valid
but above normal operating
range
4334 18
Check
Engine
Amber
3574
Aftertreatment 1 Diesel
Exhaust Fluid Doser
Absolute Pressure
Aftertreatment 1 Diesel Exhaust
Fluid Pressure Sensor - Data valid
but below normal operating
range
REFERENCE
