MacDon M155 - Windrower Operation Basics

OPERATOR’S STATION
1. Turn ignition key to RUN , or start the eng ine.
2. Press PROGRAM (A) and SELECT (C) on cab display
module (CDM) to enter Programming Mode.
• WINDROWER SETUP? is displayed on the
upper line.
Figure 3.184: M155 CDM Programming Buttons
3. Press SELECT (B) until DIAGNOSTIC MODE? is
displayed in upper line.
• NO/YES is displayed on the lower line .
4. Press right (A) arrow to select Yes. Press SELECT (B).
Figure 3
.185: M155 Diagnostic Functions
5. Press SELECT (D) until ACTIVATE FUNCTIONS? is
displayed on the upper line.
• NO/YES is displayed on the lower line .
6. Press right (C) arrow to select YES. Press
SELECT (D).
CAUTION
Check to be sure all bystanders have cleared the area.
Figure 3.186: M155 Functions
