8.5 Cab Display Module (CDM) Error Codes
NOTE:
In the c ase of dual codes being shown for an item (primarily the solenoid valves), the first code indicates a
SHORT CIRCU IT cond itio n, while th e second code indicates an OPEN CIRCUIT condit ion. That is, E41 would be
a SHORT in the Reel Aft solenoids (P55, P59), while E141 would indicate an O PEN circuit.
Codes CDM Display Description
E1
E2 RTCH NOT ALLOWED Return to cut activated with the header off
E3 CDM CAN BUS
ERROR
CANBUS err
or with CDM: check electrical connections
E4
HDR DRV NOT ALLOWED Header engage switch activated while in engine-forward
E5 CHECK HEADER ID
Header ID
change has been detected while the header was
engaged
E6 TEMP GAUGE SHORT Wiring / connection problem
E7 SPEED STICK SH ORT Wiring / connection problem
E8 HEADER
ENABLE SHORT
Wiring
/ connection problem
E9 WCM ENABLE SHORT Wiring / connection problem
E10 CDM INTERNAL ERROR Internal hardware or software problem
E11 CDM PO
WER UP
CDM mo
dule did not power up correctly
E12 WCM POWER UP W CM module did not power up correctly
E13 FUEL SOLENOID WCM fuel solenoid output fault detected
E14
E15
KNIFE D RIVE PWM P68 Knife drive – PWM solenoid P68 drive fault detected
E16
DR
APER D RIVE P WM P 69
Dr
aper drive – PW M solenoid P69 drive fault detected
E17 REEL DRIVE PWM P70 Reel drive – PWM solenoid P70 drive fault detected
E
18
E19 E119 Load Sense P75 Disc blo ck v alv e – Solenoid P75 drive fault detec ted
E20
E21 E121 REVERSER P106 Reverser solenoid P 106 fault detected
E22
E23 E123 REVERSER Reverser – solenoid (P65, P66, P67) fault detected
E24 E124 DECK SHFT RIGHT P95 Right deck shift solenoid P95 fault detected
E25 E125 DECK SHFT LEFT P96 Left deck shift solenoid P96 fault detected
E26 E126 DWA UP DWA raise solenoid P72, P73 fault detected
E27 E127 DWA DOWN DWA lower solenoid P72, P73, fault detected circuit
E28 E128 TILT RETRACT Header tilt retract solenoid P54, fault detected
E29 E129 TILT EXTEND Header tilt extend solenoid P53, P54, fault detected
E30 E130 4 WAY VALVE P62 4-way valve solenoid P62 fault detected
