OPERATOR’S STATION
Cab-Forward, Engine Running, Header Engaged, Draper Header, Index Switch OFF
Scroll through display with cab display module (CDM) switch or gro un d speed lever (GS L) switch.
Display(LowerorUpperLine)
Description
#####.# ENGI
NE HRS Total engine operating time.
#####.# HEADER HRS
Total header operating time.
##.# ACRES/HOUR
##.# H ECTARES/HOUR (if metric)
Actual cutting rate in acres (hectares)/hour.
###.# SUB A
CRES
###.# SUB H
ECTA RES (if me tric)
Area cut si
nce last reset. To reset, display SUB ACRES on lower line,
andholddo
wn program switch until display resets (5–7 seconds).
###### TOTAL ACRES
###### TOTAL HECT (if metric)
Total area cut by machine.
##.## REEL MPH
##.## REEL KPH (if metric)
##.## R EEL SEN SOR (flashing)
Reel pe r
ipheral speed.
Sensor D
isabled. MPH or KPH and SENSOR alternate at 1 second
interva
ls.
##.# DRAPER SPEED Draper speed (0.0–11.0).
#### KNIFE SPEED
#### KNIFE SENSOR
Knife speed In strokes per minute.
Sensor Disabled. SPEED and SENSOR alternate at 1 second intervals.
##.# H
EADER HEIGHT
##.#
HEADER SENSOR
Dista
nce setting (00.0–10.0) between cutterbar and ground.
Sens
or Disabled. HEIGHT and SENSOR alternate at 1 second
inte
rvals.
##.# HEADER ANGLE
##.# HEADER SENSOR
Angle setting (00.0–10.0). Header relative to ground.
Sensor Disabled. ANGLE and SENSOR alternate at 1 second intervals.
##.# L FLOAT R ##.#
FLOAT SENS DIS ABLED
Left and right float setting (0.0–10.0).
Sensor Disabled.
##
#°CorFHYDOILTEMP
##
#°CorFHYDSENSOR
Hydraulic oil temperature.
Sensor Disabled. TEMP and SENSOR alternate at 1 second intervals.
LOAD|■■■■||####
Bar graph representing hydraulic operating pressure. Full scale
is pre-programmed overload pressure (2500–5000 psi). If sensor
disabled, LOAD does not display
8
#
#.# VOLTS Engine electrical system operating voltage.
SCROLL
SUB-MENU (Low er Line Only)
#### KNIFE SPEED
##.# HEADER HEIGHT
LOAD|■■■■|■■■■| ####
##.## REEL MPH
##.# DRAPER SPEED
Displays sub-menu after 2–3 seconds. Press SELECT to cancel.
Scroll throug h sub-menu display w ith CDM switch.
KNIFE SPD OVERLOAD Knife or Disc Speed Drops Below Programmed Value.
8. The LOAD sensor to m onitor knife/conditioner circuit pressure is optional. To monitor reel/auger circuit pressure,
relocate sensor as per Form MD #169031, which is available through your Dealer.
147649 81 Revision A
