8.2.3 Lubrica
nts, Fluids, and System Capacities
CAUTION
To avoid injury or death, do not allow ANY machine fluids to enter the body.
Table 8.15 System Capacities
Lubricant/Fluid Location Description Capacity
Grease
As required unless
otherwise specified
SAE multi-purpose.high temperature
extreme p ressure (EP2) performance
with 1% max Molybdenum Disulphide
(NLGI Grade 2) lithium base
Diesel fuel
Fuel tank
Diesel Grade No.2, or Diesel Grade
No.1and2mix
40
; r efer to 8.2.2
Fuel Specifications, page 465 for
more information
97 US gallons
(378 liters)
Hydraulic
oil
Hydraulic
reservoir
SAE 15W-40 compliant with SAE specs
for API class SJ an d CH-4 engin e oil.
17.2 US gallons
(65 liters)
Gear box
2.2 US quarts
(2.1 liters)
Gear lubricant
Wheel drive
41
SAE 75W-90, API service class
GL-5.fully synthetic gear lubricant,
(SAE J2 360 preferred)
1.5 US quarts
(1.4 liters)
Antifreeze
Engine c
ooling
system
ASTM D-6210 and
Fleetguard ES Compleat
®
See below
7.3 US gallons
(27.5 liters)
42
Engine oil Engine oil pan
SAE 15W-40 compliant with SAE specs
for API class SJ and CH-4 Engine Oil
11.6 US quarts
(11 liters)
Air conditioning
refrigerant
43
Air conditioning
system
R134A
5 lb (2.27 kg)
Air conditioning
refrigerant oil
44
Air conditioning
system total
capacity
PAG SP-15 8.1 fl. oz. (240 cc)
40. Optional when operating temperature is below 0°C. (32°F).
41. SAE 85W-140 API Service Class G L-5. Extreme Pre ssu re G e ar Lu b ric an t is used bef ore initial change.
42. Equal parts with water, high quality, soft, de-ionized o r distille d w a te r as re commended by Supp lie r.
43. For prior models who have not upgraded to 5 lbs of refrigerant order Kit MD #183180, which includes decal to
advise of systems 5 lbs charge requirement. Refer to Service Bulletin 1254.
44. New compressor (MD #203013) comes filled. If installing on 201 4 and prior, refer to Service Bulletin 12 54.
147649 466 Revision A
