3.3.7 A rmrest Angle
Adjusts ang le
of armrest.
INCREASE: R ot
ate knob (A) clockwise.
DECREASE: Rot
ate knob (A) counterclockwise.
Figure 3.10: Armrest Angle
3.3.8 Lumbar Support
Adjusts stiffness of seat back.
INCREASE: Rotate knob (A) upward.
DECREASE: Rotate knob (A) downward.
Figur
e 3.11: Lumbar Support
