MacDon M155 - Cab-Forward, Engine Running, Header Disengaged; Cab-Forward, Engine Running, Header Engaged, Auger Header Index Switch off; Engine-Forward, Engine Running

OPERATOR’S STATION
Engine-Forward, Engine Running
Display Description
ROAD GEAR (Upp
er Line)
Ground speed r
ange switch in high range.
#####.# ENGINE H RS (Upper or Lower Line)
To tal engine operating time.
#####.# HEADER HRS (Upper or Lower Line)
Total header operating time.
###### TOTA
L ACRES (Upper or Lower Line)
###### TOTA
L HEC T (if Metric)
Total area cut by machine.
##.# HEADER HEIGHT (Upper or Lower Line) Distance setting (00.0–10.0) between cutterbar and ground.
##.# HEADER ANGLE (Upper or Lower Line) Angle setting (00.0–10.0) header relative to ground.
### °C or F
HYD OIL TEMP Hydraulic oil temperature.
##.# VOLTS (Upper or Lower Line)
Engine electrical system operating voltage.
SCROLL (Lower Line)
Displays above items after 2–3 seconds; press SELECT
to cancel.
Cab-F
orward, Engine Running, Header Disengaged
Scroll through display with cab display module (CDM) switch or gro un d speed lever (GS L) switch.
Display (Lower or Upper Line) Description
#####.# ENGINE HRS
Total engine operating time.
###
##.# HEADER HRS Total header operating time.
###.# SUB ACRES
###.# SUB H ECTARES (if metric)
Area cut since last reset. To reset, display SUB ACRES on lower line,
and hold down Program s w itch until display reset s (5– 7 se co nds).
###### TOTAL ACRES
###### TOTAL HECT (if metric)
Total area cut by machine.
#
#.# HEADER HEIGHT
D
istance setting (00.0–10.0) between cutterbar and ground.
##.# HEADER ANGLE Angle setting (00.0–10.0) header relative to ground.
##.# L FLOAT R ##.# Float setting (0.0–10.0).
### °C or F HYD OIL TEMP Hydraulic oil temperature.
##.# VOLTS
Engine electrical system operating voltage.
SCROLL (Lower Line) Displays above items after 2–3 seconds; press SELECT to cancel.
Cab-Forward, Engine Running, Hea der Engaged, Auger Header Index Switch OFF
Scroll through display with cab display module (CDM) switch or gro un d speed lever (GS L) switch.
Display (Lower or U pper Line) Description
#####.# ENGINE HRS
To tal engine operating time.
#####.# HEADER HRS Total header operating time.
147649
7
7
