MAINTENANCE AND S ERVICING
Turning the Eng ine Manually
To manually turn the engine with the flywheel, an access hole is provided on the left cab-forward side for a
barring tool that is available from Cummins.
DANGER
To avoid bodily injury or death from unexpected startup of the machine, always stop the engine and remove
the key from the ignition before leaving the operator ’s seat for any reason.
1. Stop engine and remove ignition key.
2. Open the hood to the lowest position, refer to 5.2.1 Opening Hood (Lower Position), page 306.
3. Open left ca b-fo rward sid e p latfo rm , refer to 5.3.1 Opening Platforms (Standard Position), page 309.
4. Remove positive (red) cables (A) from battery posts
first, then remove negative (black) cables (B) from both
battery posts.
Figure 5.50: Battery Terminal Location
147649 333 Revision A
