OPERATOR’S STATION
3.7.5 H ID Auxi
liary Lighting (Optional)
Two optional High Intensity Discharge (HID) lights (MD #B5596) provide additional lighting during field operation.
If insta lled , HID auxiliary lighting is located on the m irror
supports (A) and operates in cab-forward mode only.
Figure 3.28: HID Auxiliary Lights (Optional)
Optional HID au xilia ry lighting is activated with th e lig h t
switch (B) in the FIELD position.
Figure 3.29: Field Light Switch
147649 53 Revision A
