MacDon M155 - Attaching a D-Series Header: Hydraulic Center-Link Without Self-Alignment

OPERATION
19. Connect header drive hoses (A) and electrical
harness (B) to header. Refer to the draper header
operator’s manual.
Figure 4.123: H e ader Dri ve Ho ses and Harn es s
20. Connect reel hydraulics (A) at right cab-forward
side of windrower. Refer to the draper header
operator’s manual.
Figure 4.124: Reel Hydraulics
Attaching a D-Series Header: Hydraulic Center-Link without Self-Alignment
NOTE:
Draper
header boots must b e installed onto the windrower lift linkage before starting this procedure. Refer to
Attach
ing Header Boots, page 213.
DANGER
To avoid bodily injury or death from unexpected startup of the machine, always stop the engine and remove
the key from the ignition before leaving the operator ’s seat for any reason.
147649 219 Revision A
