MAINTENANCE AND S ERVICING
2. Adjust lights with screws (A).
Figure 5.142: Field Lights
Replacing Field Light Bulb
1. Remove two
screws (A), and remove light assembly.
2. Replace bu
lb as described in Re p lacing Field Light
Bulb, pag
e 381.
Figure 5.143: Field Lights
Flood Lights: Forward
Adjusting Forward Flood Lights
The fo
rward flood lights are NOT adjustable .
Repla
cing Bulb in Cab-Forward Flood Light
DANGE
R
To avoid bodily injury or death from unexpected startup of the machine, always stop the engine and remove
the key from the ignition before leaving the operator ’s seat for any reason.
Replace bulbs as follows:
1. Shut down engine and remove key. Turn lights OFF.
147649 381 Revision A
