MacDon M155 - Beacon Lighting (Optional)

OPERATOR’S STATION
• Red lights (C) in hood
NOTE:
The hazard ligh
ts will be automatically activated when
certain condi
tions a re met. The windrower must be
cab-forward,
medium range, brake OFF, and header OFF.
IMPORTANT:
Optional red tail lighting an d marking kit must be installed
so that road travel in the cab-forwa rd mode complies with
road travel regulations. See your MacDon Dealer.
Figure 3.25: Cab Forward: Rear View
3.7.4 Beacon Lighting (Optional)
MD #B5582
The beaco
n lights (A) are functional when the ignition and
the beaco
nswitch(B)areON.
The beaco
ns MUST be used when driving on the road
where req
uired by law.
Figure 3.26: Cab-Forward: Front View
Fig
ure 3.27: Beacon Light Switch
147649 52 Revision A
