OPERATOR’S STATION
Testing the Double Windrower Attachment (DWA) Drive Activate Function Using the Cab
Display Mod ule (CDM)
IMPORTAN T:
Do not over-speed a drive for a significant length of time. Doing so can lead to vibration, belt failures, or
other over-speeding related problems.
NOTE:
• DWA must be attached to windrower and activated under the WINDROWER SETUP menu. For more
information, refer to Activating the Double Windrower Attachment (DWA), page 110.
• Engine MUST be running to perform this procedure.
1. Turn ignition key to RUN , or start the eng ine.
2. Press PROGRAM (A) and SELECT (C) on cab display
module (CDM) to enter Programming Mode. Press
SELECT (C).
• WINDROWER SETUP? is displayed on the
upper line.
Figure 3
.209: M155 CDM Programming Buttons
3. Press SELECT (B) until DIAGNOSTIC MODE? is
displayed in upper line.
• NO/YES is displayed on the lower line .
4. Press right (A) arrow to select Yes. Press SELECT (B).
Figure 3.210: M155 Diagnostic Functions
147649 151 Revision A
