OPERATOR’S STATION
3. Press SELECT (B) until DIAGNOSTIC MODE? is
displayed in upper line.
• NO/YES is displayed on the lower line.
4. Press right (A) arrow to select Yes. Press SELECT (B).
Figure 3.20
6: M155 Diagnostic Functions
5. Press SELEC T (B) until ACTIVATE FUN CTIONS? is
displayed on the upper line.
• NO/YES is displayed on the lower line.
6. Press right (A) arrow to select YES. Press SELECT (B).
• ACTIVATE HEADER HT is displayed on the
upper line.
Figure 3.207: M 155 Functions
CAUTION
Check to be sure a ll bystanders have cleared the area.
7. Press SELECT (E) until D ISC DRV SPD XXXX is
displayed on the upper line.
IMPORTANT:
Do NOT over speed the disc drive.
8. Press and hold HAZARD (C) button.
• Press left (B) arrow to decrease disc speed.
• Press right (D) arrow to increase disc speed.
Verify the disc drive is functioning properly.
9. Release the HAZARD (C) button. The disc drive
will stop.
Figure 3.208: M 155 D isc Drive
10. Press PROGRAM to exit Programming Mode or press
SELECT to proceed to next ACTIVAT E FUNCTION.
