OPERATOR’S STATION
3.4 Training Seat
A wall-mounted fold-up training seat complete with seat belt is provided.
WARNING
• The training seat is provided for an experienced Operator of the machine when a new Operator is
being trained.
• The training seat is NOT intended as a PASSENGER SEAT or FOR USE BY CHILDREN. USE THE SEAT
BELT whenever operating the machine or riding as a Trainer.
• KEEP ALL OTHER RIDERS OFF THE MACHINE.
For storage, lift seat (B) and secure with latch (A).
Figure 3.12: Training Seat
To lower seat, lift latch (A) and lower seat (B).
Figure 3.13: Training Seat
147649 46 Revision A
