MAINTENANCE AND S ERVICING
2. In the grill of the hood, remove two screws (A) from
light (B), and rem ove light.
3. Remove connector from light.
4. Connect wiring harness to new light (B) and install light
with screws (A).
Figure 5.161: Red Tail Lights
Replacing the Bulbs in Beacon Lights (if installed)
Beacon war
ning lights are available as an optional Dealer-installed attachment (MD #B5582).
DANGER
To avoid bodily injury or death from unexpected startup of the machine, always stop the engine and remove
the key from the ignition before leaving the operator ’s seat for any reason.
To replace the halogen bulb inside the beacon warning
lights, follow th es e steps:
1. Shut down engine and remove key. Turn beacons OFF.
NOTE:
Hold onto the handholds (B) on the cab front
corners and stand on the header anti-slip strips,
or stand on the maintenance platform when
accessing the beacons (A).
Figure 5.162: Warning Beacons
147649 389 Revision A
