OPERATOR’S STATION
Cab-Forward, Engine Running, Header Engag ed, Auger Header Index Switch O N
Scroll through display with cab display module (CDM) switch or gro un d speed lever (GS L) switch.
Display (Lower or Upper Line)
Description
#####.# ENGI
NE HRS Total eng ine ope ra ting time.
#####.# HEADER HRS
Total Header operating time.
##.# ACRES/HOUR
##.# HECTARES/HOUR (If Metric)
Actual cutting rate in acres (hectares)/hour.
###.# SUB A
CRES
###.# SUB H
ECTA RES (If Me tr ic)
Area cut si
nce last reset. To reset, display SUB ACRES
on lower li
ne, and hold down program switch until display
resets 5–
7 seconds).
###### TOTAL ACRES
###### TOTAL HECT (If Metric)
Total area cut by machine.
##.## ##.# REEL IND.
##.## REEL SENSOR
Reel Per
ipheral speed along with ground speed in mph
or km/h.
Sensor d
isabled. IND and SENSOR alternate at 1 second
interva
ls.
##.# AUGER SPEED
##.# AUGER SENSOR
Auger rotational speed (4.7–9.9).
Sensor disabled. SPEED and SE NSOR alternate at
1 second intervals.
#### KNIFE SPEED
#### KNIFE SENSOR
Knife speed In strokes per minute.
Sensor disabled. SPEED and SE NSOR alternate at
1 second intervals.
##.#
HEADER HEIGH T
##.#
HEADER SENSOR
Dist
ance setting (00.0–10.0) between cutterbar and ground.
Sens
or disabled. HEIGH T and SEN SOR alternate at
1sec
ond intervals.
##.# HEADER ANGLE
##.# TILT SENSOR
Angle setting (00.0–10.0) header relative to ground.
Sensor disabled. ANGLE and SENSOR alternate at
1 second intervals.
##.# L FLOAT R ##.#
FLOAT SENS DISABLED (If Sensor Disabled)
Left and right float setting (0.0–10.0).
Sensor disab led.
L
OAD|■■■■||####
Bar graph representing hydraulic operating pressure.
Full scale Is preprogrammed overload pressure
(2500–5000 psi). If sensor disabled, LOAD does not
display
6
### °C or F HYD OIL TEMP
### °C or F HYD TEMP
H
ydraulic oil temperatu re.
Sensor Disabled. TEMP and SENSOR alternate at
1 second intervals.
6. The LOAD sensor to monitor knife/conditioner circuit pressure is optional. To monitor reel/auger circuit pressure,
relocate sensor as per Form MD #169031, which is available through your Dealer.
147649 79 Revision A
