OPERATOR’S STATION
Display (Lower or Upper Line) Description
##.# ACRES/HO
UR
##.# HECTARES
/HOUR (If Metric)
Actual cuttin
grateinacres(hectares)/hour.
###.# SUB ACRES
###.# SUB HECTARES (If Metric)
Area cut since last reset. To reset, display SUB ACRES
on lower line, and hold down program switch until display
resets (5–7 seconds).
###### TOTAL ACRES
###### TOTAL HECT (If Metric)
Tota l area cut by machine.
##.## REEL
RPM
##.## REEL
SENSOR
Reel rotational speed.
Sensor Disabled. RPM and SENSOR alternate at 1 second
intervals.
##.# AUGER SPEED Auger rotational speed (4.7–9.9).
#### KNIF
E SPEED
#### KNIF
E SENSOR
Knife spe
ed in strokes per minute.
Sensor Di
sabled. SPEED and SENSOR alternate at
1 second
intervals.
##.# HEADER HEIGHT
##.# HEA DER SENSOR
Distance setting (00.0–10.0) between cutterbar and ground.
Sensor Disabled. HEIGHT and SENSOR alternate at
1 second intervals.
##.# HEADER ANGLE
##.# HEA DER SENSOR
Angle setting (00.0–10.0) header relative to ground.
Sensor Disabled. ANGLE and SENSOR alternate at
1 second intervals.
##.# L
FLOAT R ##.#
FLOA
TSENSDISABLED
Left a
nd right float setting (0.0–10.0).
Sens
or Disabled.
LOAD|■■■■||####
Bar graph representing hydraulic operating pressure.
Full scale is preprogrammed overload pressure
(2500–5000 psi). If sensor disabled, LOAD does not
display
5
.
###
°C or F H YD OIL TEMP
###
°C or F HYD TEMP
Hydraulic oil temperature.
Sensor Disabled. TEMP and SENSOR alternate at
1 second intervals.
##.# VOLTS
Engine electrical system operating voltage.
SC
ROLL
S
UB-MENU (Lower Line Only)
#
### KNIFE SPEED
#
#.# HEADER HEIGHT
L
OAD|■■■■|■■■■| ####
D
isplays sub-menu after 2–3 seconds. Press SELECT to
c
ancel. Scroll through sub-menu display with CDM switch.
5. The LOAD sensor to monitor knife/conditioner c ircuit pressure is optional. To monitor reel/auger circuit pressure,
relocate sensor as per Form MD #169031, which is available through your Dealer.
147649 78 Revision A
