OPERATION
4.4.7 Return t
oCut
The M-Series m onitoring system w ill assist you in maintaining the desired cutting height with the RETURN TO CUT
feature. This feature can be turned OFF or ON with a switch on the cab display module (CDM).
The return to cut (RTC) feature provides preset cutting height and tilt angle settings for the header.
If desired, the CDM can be programmed so only the cutting height feature is active.
The AUTO RAISE HEIGHT feature allows you to raise the header to a preselected height while in the RETURN TO
CUT mode. Refer to Programming the Auto Raise Height Feature, page 209.
Refer to the following for RTC programming and operating procedures:
• Programming the Return to Cut Feature, page 207
• Using the Return to Cut Feature, page 208
Programming the Return to C ut Feature
Figure 4.98: Operator Console
Pro
gram the RETURN TO CUT (RTC) feature as follows:
CAUTION
Check to be sure all by stan d e rs have cleared the area.
1. Start and windrower and engage the header.
2. Set RETURN TO CUT switch (A) to OFF (indicator light is OFF).
3. Adjust the header to the desired cutting height with the HEADER UP (B) or HEADER DOWN (C) switches on
the ground speed lever (GSL). The cab display module (CDM) displays between 00.0 and 10.0 at (D).
147649 207 Revision A
