OPERATOR’S STATION
3.13 Operator Amenities
The operator ’s station includes the following amenities:
Operator ’s Console
A - Aux iliary powe r outlet
B - Utility tray (un de r armrest)
C - Cigarette lighter
D - Ashtray / cup h older
E - Utility tra y
Figure 3.38: Console
Window Shades (Optional)
Retractable window shades (A) can be installed for the front
and rear windows.
Figure
3.39: Window Shades (Optional)
Auxil
iary Outlets
Two au
xiliary po wer outlets are located on either side of
the wi
per motor cover/storage tray behind the Operator
(cab-
forward m ode).
Figure 3.40: Auxiliary Power Outlets
A - Auxiliary Power Outlet B - Auxiliary Power Outlet
C - Battery Terminal D - Ground Terminal
E - Switched Terminal
