OPERATOR’S STATION
Cab-Forward, Engine Running, Header Engaged, Draper Header, Index Switch ON
Scroll through display with cab display module (CDM) switch or ground speed lever (GSL) s witch.
Display (Lower or Upper Line)
Description
#####.# ENGI
NE HRS Total engine operating time.
#####.# HEADER HRS
Total header operating time.
##.# ACRES/HOUR
##.# HEC TARES/HOUR (if metric)
Actual cutting rate in acres (hectares)/hour.
###.# SUB A
CRES
###.# SUB H
ECTARES (if metric)
Area cut si
nce last reset. To reset, display SUB ACRES on lower line
and hold do
wn program switch until display resets (5–7 Seconds).
###### TOTAL ACRES
###### TOTAL HECT (if metric)
Total area cut by machine.
##.## ##.# REEL IND
REEL.SENSOR
Reel peripheral speed along with ground speed in mph or km/h.
Sensor Disabled. IND and SENSOR alternate at 1 second intervals.
##.# ##
.# DRAP INDX
Draper
speed along with ground speed in mph or km/h.
#### KNIFE SPEED
#### KNIFE SENSOR
Knife speed in strokes per minute. Sensor Disabled.
SPEED and SEN SOR alternate at 1 second intervals.
##.# HEADER HEIGHT
##.# HEADER SENSOR
Distance setting (00.0–10.0) between cutterbar and ground.
Sensor Disabled. HEIGHT and SENSOR alternate at 1 second
intervals.
##.#
HEADER ANGLE
##.#
HEADER SEN SOR
Angl
e setting (00.0–10.0) header relative to ground.
Sens
or Disabled. ANGLE and SENSOR alternate at 1 second intervals.
##.# L FLOAT R ##.#
FLOAT SENS DISABLED
Left and right float setting (0.0–10.0).
Sensor Disabled.
LOAD|■■■■| | ####
Bar
graph representing hydraulic operating pressure. Full scale
is
pre-programmed overload pressure (2500–5000 psi). If s ensor
di
sabled, LOAD does not display
9
##.# VOLTS
Engine electrical system operating voltage.
SCROLL
SUB-MENU (lower line only)
#### KNIFE SPEED
##.# HEADER HEIGHT
LOAD|■■■■|■■■■|
##.## ##.# REEL IND
##.# ##.# DRAP INDX
Displays sub-menu after 2–3 seconds. Press SELECT to cancel.
Scroll through sub-menu d isp lay with CDM s w itc h.
##.## REEL MIN RPM (lower line) Reel speed drops below programmed set-point.
MINIMUM (lower lin e)
Reel speed at zero ground speed.
9. The LOAD sensor to monitor knife/conditioner c ircuit pressure is optional. To monitor reel/auger circuit pressure,
relocate sensor as per Form MD #169031, which is available through your Dealer.
147649 82 Revision A
